Knuckle Boom Cranes (PM Series) - (Tadano)
Descriptions
The PM 11 combines a strong weight-to-capacity ratio with reliable performance and ease of use, making it a versatile choice for medium-duty lifting tasks. Performance made simple.
Contact for Pricing
Contact for availability
Max Cap
2
Boom
15.4 ft - 24.6 ft
Jib
24.6 ft - 33.1 ft
Total Hrs
New
Request Pricing
Contact for availability
Max Cap
3
Boom
15.4 ft - 24.6 ft
Jib
24.6 ft - 33.1 ft
Total Hrs
New
Request Pricing
Contact for availability
Max Cap
3
Boom
16.1 ft - 25.1 ft
Jib
25.3 ft - 33.6 ft
Total Hrs
New
Request Pricing
PM 11021 | PM 11022 | PM 11023 | PM 11023 + J12 | PM 11024 | PM 11024 + J12 | PM 11025 | |
|---|---|---|---|---|---|---|---|
| Spec Sheet | |||||||
| Spec Sheet | - | - | - | - | - | - | - |
| Max. Pressure | - | - | - | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - | - | - | - |
| Max. Lifting Moment | 80430 ft Ibs | 77630 ft Ibs | 74750 ft Ibs | 74750 ft Ibs | 72000 ft Ibs | 72000 ft Ibs | 63850 ft Ibs |
| Hydraulic Horizontal Outreach | 19′ | 25′ 3″ | 31′ 6″ | 48′ 11″ | 38′ 1″ | 55′ 1″ | 44′ 3″ |
| Hydraulic Vertical Outreach | 29′ 10″ | 36′ 1″ | 42′ 4″ | 59′ 1″ | 48′ 7″ | 65′ 11″ | 53′ 10″ |
| Recommended oil flow | - | - | - | - | - | - | - |
| Slewing torque | - | - | - | - | - | - | - |
| Stabilizer Spread available | - | - | - | - | - | - | - |
| Slewing angle | 400° | 400° | 400° | 400° | 400° | 400° | 400° |
| Stabilizer control Radio Wireless | Manual | Manual | Manual | Manual | Manual | Manual | Manual |
| Width | 2′ 7″ | 2′ 7″ | 2′ 7″ | - | 2′ 7″ | - | 3′ |
| Height | 6′ 9″ | 6′ 9″ | 6′ 9″ | - | 6′ 9″ | - | 6′ 9″ |
| Length | 7′ 11″ | 7′ 11″ | 7′ 11″ | - | 7′ 11″ | - | 7′ 11″ |
Standard
Standard
Standard
Standard
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Standard
