Series Specs
PM 11521 P | PM 11522 P | PM 11523 P | PM 11523 +J12 P | PM 11524 P | PM 11524 + J12 P | PM 11525 P | |
|---|---|---|---|---|---|---|---|
| Spec Sheet | |||||||
| Spec Sheet | - | - | - | - | - | - | - |
| Max. Pressure | - | - | - | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - | - | - | - |
| Max. Lifting Moment | 82280 ft Ibs | 79390 ft Ibs | 76160 ft Ibs | 79390 ft Ibs | 73600 ft Ibs | 76160 ft Ibs | 65640 ft Ibs |
| Hydraulic Horizontal Outreach | 19′ | 25′ 3″ | 31′ 6″ | 48′ 11″ | 38′ 1″ | 55′ 1″ | 44′ 3″ |
| Hydraulic Vertical Outreach | 29′ 10″ | 36′ 1″ | 42′ 4″ | 59′ 1″ | 48′ 7″ | 65′ 11″ | 53′ 10″ |
| Recommended oil flow | - | - | - | - | - | - | - |
| Slewing torque | - | - | - | - | - | - | - |
| Stabilizer Spread available | - | - | - | - | - | - | - |
| Slewing angle | 400° | 400° | 400° | 400° | 400° | 400° | 400° |
| Stabilizer control Radio Wireless | Manual | Manual | Manual | Manual | Manual | Manual | Manual |
| Width | 2′ 7″ | 2′ 7″ | 2′ 7″ | - | 2′ 7″ | - | 3′ |
| Height | 6′ 9″ | 6′ 9″ | 6′ 9″ | - | 6′ 9″ | - | 6′ 9″ |
| Length | 7′ 11″ | 7′ 11″ | 7′ 11″ | - | 7′ 11″ | - | 7′ 11″ |
Equipment
Manual pull-out outrigger booms
Standard
Multi-function radio control
Standard
Proportional hydraulic control valve block
Standard
Rack
Standard
Safety Kit for outriggers
Standard
Sequential arm extension exit
Standard
A
Air/oil heat exchanger
Optional
Electro-hydraulic slewing limiter
Optional
Hose racks
Optional
Hydraulic pull-out outrigger booms
Optional
Hydraulic winch on crane
Optional
Jib
Optional
LC configuration
Optional
LMU CE control system for mechanical extensions
Optional
Manual extensions
Optional
Tank
Optional
Third operating point
Optional
Top seat
Optional
Air Oil Heat Exchanger
Standard
