Series Specs
PM 19022 | PM 19023 | PM 19024 | PM 19025 | |
|---|---|---|---|---|
| Spec Sheet | ||||
| Spec Sheet | - | - | - | - |
| Max. Pressure | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - |
| Max. Lifting Moment | 122960 ft Ibs | 118620 ft Ibs | 116450 ft Ibs | 114280 ft Ibs |
| Hydraulic Horizontal Outreach | 26′ 3” | 33′ 6” | 41′ 0” | 48′ 5” |
| Hydraulic Vertical Outreach | 39′ 1” | 46′ 1” | 53′ 4” | 60′ 8” |
| Recommended oil flow | - | - | - | - |
| Slewing torque | - | - | - | - |
| Stabilizer Spread available | - | - | - | - |
| Slewing angle | 400° | 400° | 400° | 400° |
| Stabilizer control Radio Wireless | Manual | Manual | Manual | Manual |
| Width | 3′ 2” | 3′ 2” | 3′ 2” | 3′ 4” |
| Height | 7′ 5″ | 7′ 5″ | 7′ 5″ | 7′ 5″ |
| Length | 8′ 1″ | 8′ 1″ | 8′ 1″ | 8′ 1″ |
Equipment
Manual pull-out outrigger booms
Standard
Rack
Standard
Regenerative valve
Standard
A
Air/oil heat exchanger
Optional
Electro-hydraulic slewing limiter
Optional
Hose racks
Optional
Hose reel
Optional
Hydraulic flip-up outriggers
Optional
Hydraulic pull-out outrigger booms
Optional
Hydraulic winch on crane
Optional
LC configuration
Optional
LMU CE control system for mechanical extensions
Optional
Manual extensions
Optional
Multi-function radio control
Optional
Proportional hydraulic control valve block
Optional
Safety Kit for outriggers
Optional
Slewing limitation with variable calibration
Optional
Slewing limiter valve kit
Optional
Tank
Optional
Air Oil Heat Exchanger
Standard
