Series Specs
PM 28522 SP | PM 28523 SP | PM 28524 SP | PM 28524 SP + J813.20 | PM 28524 SP + J814.20 | PM 28524 SP + J815.20 | PM 28525 SP | PM 28525 SP + J613.20 | PM 28525 SP + J614.20 | PM 28526 SP | PM 28526 SP + J613.20 | PM 28526 SP + J614.20 | PM 28527 SP | PM 28528 SP | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Spec Sheet | ||||||||||||||
| Spec Sheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Max. Pressure | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Max. Lifting Moment | 182270 ft lbs | 178300 ft lbs | 175220 ft lbs | 175220 ft lbs | 175220 ft lbs | 175220 ft lbs | 172420 ft lbs | 172420 ft lbs | 172420 ft lbs | 169630 ft lbs | 169630 ft lbs | 169630 ft lbs | 167180 ft lbs | 165480 ft lbs |
| Hydraulic Horizontal Outreach | 26′ 7″ | 33′ 10″ | 41′ 6″ | 66′ 11” | 72′ 12” | 79′ 1″ | 48′ 9″ | 75′ 4″ | 81′ 2 “ | 56′ 1″ | 82′ 8” | 88′ 9” | 63′ 8″ | 71′ 0″ |
| Hydraulic Vertical Outreach | 39′ 8″ | 46′ 9″ | 54′ 2″ | 79′ 7″ | 85′ 6″ | 91′ 4″ | 61′ 6″ | 87′ 9″ | 93′ 8″ | 68′ 9″ | 95′ 2″ | 101′ 3″ | 76′ 1″ | 83′ 6″ |
| Recommended oil flow | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Slewing torque | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Stabilizer Spread available | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Slewing angle | 410° | 410° | 410° | 410° | 410° | 410° | 410° | 410° | 410° | 410° | 410° | 410° | 410° | 410° |
| Stabilizer control Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless |
| Width | 3′ 6″ | 3′ 6″ | 3′ 6″ | 4′ 1” | 4′ 1” | 4′ 1” | 3′ 9″ | 4′ 1” | 4′ 1” | 3′ 10″ | 4′ 1” | 4′ 1” | 3′ 11″ | 3′ 11″ |
| Height | 7′ 9″ | 7′ 9″ | 7′ 9″ | 8′ 10” | 8′ 10” | 8′ 10” | 7′ 9″ | 8′ 10” | 8′ 10” | 7′ 9″ | 8′ 10” | 8′ 10” | 7′ 9″ | 7′ 11″ |
| Length | 8′ 3″ | 8′ 3″ | 8′ 3″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ |
Equipment
A
Air/oil heat exchanger
Standard
Double connecting rod
Standard
Hydraulic pull-out outrigger booms
Standard
Multi-function radio control
Standard
Proportional hydraulic control valve block
Standard
Rack
Standard
Safety Kit for outriggers
Standard
External mechanical slewing limiter
Optional
Hose racks
Optional
Hose reel
Optional
Hydraulic winch on crane
Optional
Hydraulic winch on jib
Optional
Jib
Optional
LC configuration
Optional
Manual flip-up outriggers
Optional
Slewing limitation with variable calibration
Optional
Tank
Optional
Air Oil Heat Exchanger
Standard
