Series Specs
PM 40522 SP | PM 40523 SP | PM 40524 SP | PM 40524 SP + J813.20 | PM 40524 SP + J814.20 | PM 40524 SP + J815.20 | PM 40525 SP | PM 40525 SP + J813.20 | PM 40525 SP + J814.20 | PM 40525 SP + J815.20 | PM 40526 SP | PM 40526 SP + J613.20 | PM 40526 SP + J614.20 | PM 40527 SP | PM 40528 SP | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Spec Sheet | |||||||||||||||
| Spec Sheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Max. Pressure | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Max. Lifting Moment | 248820 ft lbs | 242540 ft lbs | 235620 ft lbs | 235620 ft lbs | 235620 ft lbs | 235620 ft lbs | 232360 ft lbs | 232360 ft lbs | 232360 ft lbs | 232360 ft lbs | 229170 ft lbs | 229170 ft lbs | 229170 ft lbs | 226420 ft lbs | 224840 ft lbs |
| Hydraulic Horizontal Outreach | 26′ 7″ | 33′ 10″ | 41′ 6″ | 67′ 3″ | 73′ 4″ | 79′ 5″ | 48′ 9″ | 74′ 6″ | 80′ 7″ | 86′ 5″ | 56′ 1″ | 82′ 4″ | 88′ 5″ | 63′ 8″ | 71′ |
| Hydraulic Vertical Outreach | 39′ 8″ | 46′ 9″ | 54′ 2″ | 79′ 7″ | 85′ 8″ | 91′ 10″ | 61′ 6″ | 86′ 9″ | 92′ 10″ | 98′ 11″ | 68′ 9″ | 95′ 2″ | 101′ 3″ | 76′ 1″ | 83′ 6″ |
| Recommended oil flow | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Slewing torque | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Stabilizer Spread available | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Slewing angle | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous |
| Stabilizer control Radio Wireless | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard |
| Width | 3′ 8″ | 3′ 8″ | 3′ 8″ | 4′ 3″ | 4′ 3″ | 4′ 3″ | 3′ 10″ | 4′ 3″ | 4′ 3″ | 4′ 3″ | 3′ 11″ | 4′ 3″ | 4′ 3″ | 4′ | 4′ 1″ |
| Height | 7′ 9″ | 7′ 9″ | 7′ 9″ | 8′ 9″ | 8′ 9″ | 8′ 9″ | 7′ 9″ | 8′ 9″ | 8′ 9″ | 8′ 9″ | 7′ 9″ | 8′ 9″ | 8′ 9″ | 7′ 9″ | 7′ 11″ |
| Length | 8′ 3″ | 8′ 3″ | 8′ 3″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ |
Equipment
A
Air/oil heat exchanger
Standard
Double connecting rod
Standard
Hydraulic pull-out outrigger booms
Standard
Multi-function radio control
Standard
Proportional hydraulic control valve block
Standard
Slewing ring
Standard
Hose racks
Optional
Hose reel
Optional
Hydraulic flip-up outriggers
Optional
Hydraulic winch on crane
Optional
Hydraulic winch on jib
Optional
Jib
Optional
LC configuration
Optional
LMU CE control system for mechanical extensions
Optional
Manual extensions
Optional
Slewing limitation with variable calibration
Optional
Tank
Optional
Work spotlight with LED technology
Optional
Air Oil Heat Exchanger
Standard
