Series Specs
PM 48522 SP | PM 48522 SP C | PM 48523 SP | PM 48523 SP C | PM 48524 SP | PM 48524 SP + J1414.20 | PM 48524 SP + J1415.20 | PM 48524 SP + J1416.20 | PM 48524 SP C | PM 48525 SP | PM 48525 SP + J1213.20 | PM 48525 SP + J1214.20 | PM 48525 SP + J1215.20 | PM 48525 SP + J1216.20 | PM 48525 SP C | PM 48526 SP | PM 48526 SP + J1213.20 | PM 48526 SP + J1214.20 | PM 48526 SP + J1215.20 | PM 48526 SP + J1216.20 | PM 48526 SP C | PM 48527 SP | PM 48527 SP + J812.20 | PM 48527 SP + J813.20 | PM 48527 SP + J814.20 | PM 48527 SP + J815.20 | PM 48527 SP C | PM 48528 SP | PM 48528 SP + J613.20 | PM 48528 SP + J614.20 | PM 48528 SP C | PM 48529 SP | PM 48529 SP C | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Spec Sheet | |||||||||||||||||||||||||||||||||
| Spec Sheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Max. Pressure | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Max. Lifting Moment | 358640 ft lbs | 314660 ft lbs | 319380 ft lbs | 305400 ft lbs | 318800 ft lbs | 318800 ft lbs | 318800 ft lbs | 318800 ft lbs | 298790 ft lbs | 310860 ft lbs | 310860 ft lbs | 310860 ft lbs | 310860 ft lbs | 310860 ft lbs | 293580 ft lbs | 306740 ft lbs | 306740 ft lbs | 306740 ft lbs | 306740 ft lbs | 306740 ft lbs | 289970 ft lbs | 302940 ft lbs | 302940 ft lbs | 302940 ft lbs | 302940 ft lbs | 302940 ft lbs | 286320 ft lbs | 298980 ft lbs | 298980 ft lbs | 298980 ft lbs | 282960 ft lbs | 297010 ft lbs | 281730 ft lbs |
| Hydraulic Horizontal Outreach | 26′ 7″ | 23′ 5″ | 32′ | 28′ 10″ | 39′ 1″ | 71′ 8″ | 77′ 5″ | 83′ 4″ | 35′ 11″ | 46′ 5″ | 72′ 10″ | 78′ 9″ | 84′ 6″ | 90′ 5″ | 43′ 4″ | 54′ 2″ | 80′ 5″ | 86′ 1″ | 91′ 10″ | 97′ 9″ | 51′ | 61′ 10″ | 81′ 4″ | 87′ 1″ | 93′ 2″ | 99′ 3″ | 58′ 9″ | 69′ 7″ | 95′ 6″ | 101′ 5″ | 66′ 5″ | 77′ 3″ | 74′ 2″ |
| Hydraulic Vertical Outreach | 41′ 10″ | 36′ 11″ | 46′ 11″ | 42′ 2″ | 53′ 8″ | 84′ 4″ | 90′ 1″ | 95′ 10″ | 49′ 3″ | 60′ 6″ | 85′ 6″ | 91′ 4″ | 97′ 1″ | 102′ 10″ | 56′ 5″ | 67′ 11″ | 92′ 10″ | 98′ 7″ | 104′ 4″ | 110′ 1″ | 64′ | 75′ 2″ | 93′ 10″ | 99′ 7″ | 105′ 6″ | 111′ 7″ | 71′ 6″ | 82′ 6″ | 107′ 9″ | 113′ 8″ | 79′ 3″ | 89′ 9″ | 86′ 9″ |
| Recommended oil flow | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Slewing torque | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Stabilizer Spread available | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Slewing angle | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous | Continuous |
| Stabilizer control Radio Wireless | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard |
| Width | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 11″ | 4′ 11″ | 4′ 11″ | 4′ 4″ | 4′ 4″ | 4′ 11″ | 4′ 11″ | 4′ 11″ | 4′ 11″ | 4′ 4″ | 4′ 8″ | 4′ 11″ | 4′ 11″ | 4′ 11″ | 4′ 11″ | 4′ 8″ | 4′ 9″ | 5′ 2″ | 5′ 2″ | 5′ 2″ | 5′ 2″ | 4′ 9″ | 4′ 9″ | 5′ 2″ | 5′ 2″ | 4′ 9″ | 4′ 9″ | 4′ 9″ |
| Height | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 9′ 1″ | 9′ 1″ | 9′ 1″ | 8′ 2″ | 8′ 2″ | 9′ 1″ | 9′ 1″ | 9′ 1″ | 9′ 1″ | 8′ 2″ | 8′ 2″ | 9′ 1″ | 9′ 1″ | 9′ 1″ | 9′ 1″ | 8′ 2″ | 8′ 2″ | 8′ 11″ | 8′ 11″ | 8′ 11″ | 8′ 11″ | 8′ 2″ | 8′ 2″ | 9′ 1″ | 9′ 1″ | 8′ 2″ | 8′ 2″ | 8′ 2″ |
| Length | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ |
Equipment
A
Air/oil heat exchanger
Standard
Double connecting rod
Standard
Hydraulic pull-out outrigger booms
Standard
Multi-function radio control
Standard
Proportional hydraulic control valve block
Standard
Regenerative valve
Standard
Safety Kit for outriggers
Standard
Sequential arm extension exit
Standard
Slewing limiter valve kit
Standard
4mt alarm sensor
Optional
Hydraulic flip-up outriggers
Optional
Hydraulic winch on crane
Optional
Hydraulic winch on jib
Optional
Jib
Optional
Manual flip-up outriggers
Optional
Top seat
Optional
Work spotlight with LED technology
Optional
Air Oil Heat Exchanger
Standard
