Series Specs
PM 50522 SP | PM 50522 SP C | PM 50523 SP | PM 50523 SP C | PM 50524 SP | PM 50524 SP C | PM 50525 SP | PM 50525 SP C | PM 50526 SP | PM 50526 SP C | |
|---|---|---|---|---|---|---|---|---|---|---|
| Spec Sheet | ||||||||||
| Spec Sheet | - | - | - | - | - | - | - | - | - | - |
| Max. Pressure | - | - | - | - | - | - | - | - | - | - |
| Fuel Tank Capacity | - | - | - | - | - | - | - | - | - | - |
| Max. Lifting Moment | 350350 ft Ibs | 337900 ft Ibs | 326720 ft Ibs | 314780 ft Ibs | 321780 ft Ibs | 305510 ft Ibs | 314420 ft Ibs | 299450 ft Ibs | 311020 ft Ibs | 293260 ft Ibs |
| Hydraulic Horizontal Outreach | 26′ 1″ | 23′ | 31′ 6″ | 28′ 5″ | 38′ 7″ | 35′ 5″ | 45′ 11″ | 42′ 10″ | 53′ 8″ | 50′ 6″ |
| Hydraulic Vertical Outreach | 41′ 10″ | 36′ 11″ | 46′ 11″ | 42′ 2″ | 53′ 8″ | 49′ 3″ | 60′ 6″ | 56′ 5″ | 67′ 11″ | 64′ |
| Recommended oil flow | - | - | - | - | - | - | - | - | - | - |
| Slewing torque | - | - | - | - | - | - | - | - | - | - |
| Stabilizer Spread available | - | - | - | - | - | - | - | - | - | - |
| Slewing angle | 395° | 395° | 395° | 395° | 395° | 395° | 395° | 395° | 395° | 395° |
| Stabilizer control Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless | Radio Wireless |
| Width | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 4″ | 4′ 8″ | 4′ 8″ |
| Height | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ | 8′ 2″ |
| Length | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ | 8′ 4″ |
Equipment
A
Air/oil heat exchanger
Standard
Hydraulic pull-out outrigger booms
Standard
Multi-function radio control
Standard
Proportional hydraulic control valve block
Standard
Rack
Standard
Sequential arm extension exit
Standard
Single connecting rod
Standard
Slewing limiter valve kit
Standard
Hose reel
Optional
Hydraulic flip-up outriggers
Optional
Hydraulic winch on crane
Optional
Air Oil Heat Exchanger
Standard
